AIR Handling UNITS

Airtight doors

Airtight doors are used by standards in ZR and ZS central stations. They are ?lled with an
incombustible mineral wool, 40 mm thick. The internal insulation ensures high thermal and
acoustic insulating power. These doors are produced as: single leaf or double leaf doors.

Single leaf door Double leaf door

used by standards in service sections. used in fan sections, enable service
operation and disassembly of the fan unit.

Technical Standard Special
description version version

Version: • O
- made of zinc coated sheet
- lacquered • O
O
Thickness 40 mm •
Inspection windows in service stations •
Steel hinges, adjustable and with bearings •
Special sealing •
Airtight
Tightening locks, Safety locks
Lock blockade

standard version; O option
