AIR Handling UNITS
Technical characteristics of the housing
Rigidity
Housing rigidity can be determined by de?ection measurement in mm per 1m of housing
construction at overpressure and underpressure, in values described by the standard. Higher
rigidity class means smaller de?ections of the housing.
ction (mm/1m) Class KMW-climat 40 KMW-climat 70
RAL requirements EN-1886 requirements 1A
10 10 2A
- 4
Heat losses
Measurement of heat losses from the housing determines thermal conductivity U. The value
of this parameter describes the thermal conductivity class of the housing. Lower U coef?cient
means lower heat losses through the housing.
Obtained class Requirements of the PN-EN 1886:2007 standard
according to
PN-EN 1886:2007
Central station type Panel class
KMW ZR KMW ZR T1 T2 T3 T4 T5
climat 40 climat 70 U?0,5
T3 (M) T2 (M) Thermal conductivity U, W / (m2ยท K)
no
0,5<U?1,0 1,0<U?1,4 1,4<U?2,0 requirements
